The Keysight 66311B mobile communications DC source provides fast transient, exceptional sourcing, and precision measurement
66311B Mobile Communications DC Source
Danh mục: Nguồn DC cũ
Catalogue
66311B Mobile Communications DC Source
[contact-form-7 id="237" title="Yêu cầu báo giá"]
Output Ratings
- Voltage: 0 to 15 V
- Current: 0 to 3 A
- Peak Current for up to 7 ms: 5 A
Programming accuracy at 25°C ±5°C
- Voltage: 0.05%+ 10 mV
- + Current: 0.05%+ 1.33 mA
DC Readback Accuracy
- Voltage: 0.03% + 5 mV
- Current (+20 mA to + rated current): 0.2% + 0.5 mA
- Current (-20 mA to – rated current): 0.2% + 1.1 mA
- Current (-20 mA to + 20 mA range): 0.1% + 2.5 µA
