Bandwidth:

• 28 GHz (typical)
• Tr = 20.9 psec (10%-90%, probe only with N2803A)

Input Impedance

• C diff = 32 fF, C se = 48 fF
• R diff = 100 kΩ, R se = 50 kΩ

Input Voltage Range

• 1.6 Vpp. ±0.8 V(HD2&3, <-38dB), 2.5 Vpp, ±1.25 V (HD2&3 <-34dB) (with N5440A 450 Ω ZIF tip)*
• 0.8 Vpp. ±0.4 V(HD2&3, <-38dB), 1.6 Vpp, ±0.8 V (HD2&3 <-34dB) (with N5447A 200 Ω ZIF tip)*
